Panel functions for lattice corrgrams via splom — splom

These functions provide custom panel methods for lattice::splom().

Usage

splom_panel.pie(
  x,
  y,
  z,
  subscripts,
  at = pretty(z),
  cor.method = "pearson",
  ...
)

splom_panel.shade(
  x,
  y,
  z,
  subscripts,
  at = pretty(z),
  col.regions = NULL,
  cor.method = "pearson",
  ...
)

splom_panel.ellipse(x, y, col.regions, cor.method = "pearson", ...)

Arguments

x: Numeric coordinates from levelplot.
y: Numeric coordinates from levelplot.
z: Correlation values from levelplot.
subscripts: Subscripts for lattice panel. (not used)
at: Breaks for color levels.
cor.method: Correlation method (default "pearson").
...: Additional arguments passed to panel functions.
col.regions: Color palette for shading (default NULL uses internal red white blue palette).

Details

splom_panel.pie Draws pie glyphs representing correlation coefficients, omitting the diagonal.

splom_panel.shade Draws shaded rectangles with hash lines representing correlation coefficients.

splom_panel.ellipse Draws ellipses representing correlation coefficients. The position of the ellipse is determined by the position of the data, and the shape of the ellipse is determined by the correlation.

Examples

library(lattice)
pengvars <- c("bill_len", "bill_dep", "flipper_len", "body_mass")
splom(~penguins[ , pengvars], upper.panel=splom_panel.pie, pscales=0)

splom(~penguins[ , pengvars]|penguins$species, upper.panel=splom_panel.pie, pscales=0)

splom(~penguins[ , pengvars], upper.panel=splom_panel.shade, pscales=0)

splom(~penguins[ , pengvars]|penguins$species, upper.panel=splom_panel.shade, pscales=0)

splom(~penguins[ , pengvars], upper.panel=splom_panel.ellipse, pscales=0)

splom(~penguins[ , pengvars]|penguins$species, upper.panel=splom_panel.ellipse, pscales=0)
